6 INCH LIFT KIT FORD SUPER DUTY 4WD (2008-2010)


Price:
Sale price$2,649.95

Description

OVERVIEW

This suspension features luxury ride coil springs matching OE coils rates that are specifically designed for gas or diesel motors. A heavy duty track bar relocation bracket properly centers the axle and matches the steering angles created by the supplied drop pitman arm while the radius arm drop brackets maintain the Super Duty's O.E. caster angles. A steering stabilizer relocation bracket maintains proper steering control but a RC problem solver single unit is recommended with larger tires and a RC dual stabilizer is required when running 37in tires.


FEATURES

  • Easy bolt-on installation
  • Increased ground clearance
  • Levels the front with the rear of the vehicle
  • Radius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and driveability.
  • Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.

OPTIONAL PREMIUM N3 SHOCKS

  • 10-Stage Variable Valving
  • High Pressure Nitrogen Charged
  • 35mm Piston
  • Chromed Hardened 18mm Piston Rod
  • 36kN Tensile Strength
  • Spring Loaded Piston Rod Seal
  • Metallic Silver Paint
  • Silver powder coat finish
  • 3-year Manufacturer's Warranty
  •

    OPTIONAL V2 MONOTUBE SHOCKS

  • Monotube design
  • Internal floating piston
  • Nitrogen-charged
  • 46mm high-flow piston
  • Fast heat dissipation
  • 36kN Tensile Strength
  • Mounts inverted
  • T6061 brushed aluminum body
  • 3-year Manufacturer's Warranty
  •

    OPTIONAL VERTEX SHOCKS

  • 8-Stage Adjustable Damping
  • Monotube Design
  • Nitrogen-charged
  • Massive 2.5in Piston
  • 22mm Chrome-Hardened Piston Rod
  • 3-Stage Seal System
  • Heat-Treated, Alloy Bearing
  • Honed Steel Body
  • 3-year Manufacturer's Warranty
  •

    NOTES - IMPORTANT

    • Does NOT fit dually models.
    • If vehicle is equipped with rear overload leafs, they will need to be removed.
    • Gas models may require exhaust modification to clear front drive shaft

    VEHICLE FITMENT

    YEARS DRIVE MAKE MODEL
    2008-2010 4WD Ford F-250 Super Duty
    2008-2010 4WD Ford F-350 Super Duty


    RECOMMENDED TIRES & WHEELS

    TIRE WHEEL BOLT PATTERN OFFSET NOTE
    37x13.50R17 17x9 8x170 -12 -
    37x13.50R17 17x9 8x170 +0 -
    37x13.50R17 17x9 8x170 +1 -
    37x13.50R18 18x9 8x170 -12 -
    37x13.50R18 18x9 8x170 +0 -
    37x13.50R18 18x9 8x170 +1 -
    37x13.50R20 20x9 8x170 -12 -
    37x13.50R20 20x9 8x170 +0 -
    37x13.50R20 20x9 8x170 +1 -
    37x12.50R20 20x10 8x170 -25 -
    37x12.50R20 20x10 8x170 -24 -
    37x12.50R20 20x10 8x170 -19 -
    35x12.50R20 20x10 8x170 -19 -
    37x12.50R20 20x10 8x170 -18 -
    35x12.50R20 20x10 8x170 -18 -
    37x12.50R20 20x12 8x170 -44 Trimming Required
    35x12.50R20 20x12 8x170 -44 Trimming Required
    37x12.50R22 22x10 8x170 -25 -
    37x12.50R22 22x10 8x170 -24 -
    37x12.50R22 22x10 8x170 -19 -
    35x12.50R22 22x10 8x170 -19 -
    37x12.50R22 22x10 8x170 -18 -
    35x12.50R22 22x12 8x170 -44 Trimming Required
