DD Audio SC4a 4 CHANNEL LINE OUTPUT SIGNAL CONVERTER
DD Audio SC4a 4 CHANNEL LINE OUTPUT SIGNAL CONVERTER
Regular price
$69.00 USD
Regular price
Sale price
$69.00 USD
Shipping calculated at checkout.
The SC4 is a premium quality 4 channel line output signal converter. Installers will appreciate the metal chassis and easy access to features such as input channel summing, turn on selection, and grounding selection. To allow for greater OEM interface compatibility, the SC4’s input impedance allows it to integrate with most load detect systems without the need for external resistors.
Features
-
Input Summing
-
Differential-Balanced Inputs
-
Independent Variable Gains
-
Selectable Ground Isolation
-
Signal Sense Turn on (RCA and High Level)
-
Double Power Supply
-
Detachable Power and Speaker Input Terminals
-
FR4 PCB
-
Aluminum Chassis
-
OEM Load Detect Compatible
General Specifications
SC4a: 4 Channel Active Pre-Amp Signal Converter
| Operating Voltage: | 10 - 16 |
| Input Channel(s): | 4 x Speaker-Level |
| Output Channel(s): | 4 x Low-Level RCA |
| Max Current Draw (Amps): | 110mA |
| High-Level Input Voltage Sensitivity: | 2 - 20 |
| RCA Output Voltage: | 10 |
| RCA Input Impedance: | 180 |
| RCA Input S/N: | > 95dB |
| Frequency Response (Hz): | 10 ~ 50k |
| Remote Out Current: | 12V >500mA |
| Dimensions (Inches): | 3.8 x 4 x 1 |
| Dimensions (MM): | 98 x 104 x 25 |
| Shipping Weight (Lbs): | 1 |
| Price (USD): | 69 each |
